Product

Size Range

Tolerance

Surface

Coil Weight

Tensile Req.

Grades

1/8 Hard

0.8 – 11.80mm

Optional – according to requirement

Matte Finish/ Powder Drawn or Oil Drawn/ Bright

300kg max ( for 0.8 to 1.2mm)

600kg max (for 1.20-3.00mm)

800kg max (for 3.00mm & above)

650 – 750 N/mm2 or as per requirement

304/316/303/

204Cu/316Ti/

314 etc.

¼ Hard

0.8 – 11.80mm

Optional – according to requirement

Matte Finish/ Powder Drawn or Oil Drawn/ Bright

300kg max ( for 0.8 to 1.2mm)

600kg max (for 1.20-3.00mm)

800kg max (for 3.00mm & above)

700 – 900 N/mm2 or as per requirement

304/316/303/

204Cu/316Ti/

314etc.

½ Hard

0.8 – 11.80mm

Optional – according to requirement

Matte Finish/ Powder Drawn or Oil Drawn/ Bright

300kg max ( for 0.8 to 1.2mm)

600kg max (for 1.20-3.00mm)

800kg max (for 3.00mm & above)

900 – 1200 N/mm2 or as per requirement

304/316/303/

204Cu/316Ti/

314etc.

¾ Hard

0.8 – 10.00mm

Optional – according to requirement

Matte Finish/ Powder Drawn

300kg max ( for 0.8 to 1.2mm)

500kg max (for 1.20-10.00mm)

1100 – 1400 N/mm22 or as per requirement

304/316

204Cu/316Ti/

314 etc.

Spring Hard(reels)

0.8 – 2.00mm

Optional – according to requirement

Powder Drawn

450 Kg/reels

As per EN 10270-3/

ASTM A313

304/302/316/

204Cu etc.

Spring Hard (coils)

0.8 – 10.00mm

Optional – according to requirement

Powder Drawn

300kg max ( for 0.8 to 1.2mm)

500kg max (for 1.20-10.00mm)

As per EN 10270-3/

ASTM A313

304/302/316/

204Cu etc.

Soft Annealed

0.8 – 8.00mm

Optional – according to requirement

Matte Finish

600kg max

600 – 700 N/mm2 or as per requirement

304/316/303/

204Cu/316Ti/

314 etc.

Bright Annealed

0.8 – 8.00mm

Optional – according to requirement

Bright Finish

600kg max

550 – 700 N/mm2 or as per requirement

304/316/303/

204Cu/316Ti/

314 etc.

EPQ

0.8 – 8.00mm

Optional – according to requirement

Mirror Bright finish

300kg max ( for 0.8 to 1.2mm)

600kg max (for 1.20-3.00mm)

800kg max (for 3.00mm & above)

700 – 850 N/mm2 or as per requirement

304/316/303/

204Cu/316Ti/

314 etc.

Euro Coils

3.00 – 12.00mm

Optional – according to requirement

Oil Drawn/ Bright

800 – 1200 kg approx.

-

304/316/303/

204Cu/316Ti/

314 etc.

Cold Heading Wires

0.8 to 12.00mm

Optional – according to requirement

Powder Drawn or Oil Drawn

300kg max ( for 0.8 to 1.2mm)

600kg max (for 1.20-3.00mm)

800kg max (for 3.00mm & above)

450 – 600N/mm2 or as per requirement

302HQ/304HC/

409 etc.

Staple Wires

0.70 – 3.00mm

Optional – according to requirement

Oil Drawn/ Bright

500Kgs max Coils or Reels (as per requirement)

850 ~ 1300N/mm2 or as per requirement

304/L, 316/L etc
